1. Classify by application scenario

Industrial titanium mesh basket:

Titanium basket for electroplating: made of TA2 material, loaded with anode metal to improve electroplating efficiency;

Chemical filtration basket: resistant to acid and alkali corrosion, used for filtration in reaction vessels and seawater desalination equipment.

Sanitary titanium mesh basket:

Orthopedic repair network: TA1/TA2 pure titanium, supporting bone defect areas and promoting bone integration;

Dental implant mesh: precision woven structure, no rejection reaction after implantation.

2. Classify by structure

Woven titanium mesh basket: plain or diagonal weave of titanium wire, with a pore size range of 0.02-50mm, suitable for high-precision filtration;

Punched titanium mesh basket: titanium plate stamping forming, hole pattern can be customized, higher strength.

Brand: TA2, TA1, TC4.

Raw material processing: TA2 titanium plate or titanium wire is vacuum melted with impurity content<0.1%;

Molding process:

Weaving process: Titanium wire is formed by plain/diagonal weaving machine, with a mesh accuracy of ± 0.02mm;

Welding process: argon arc welding is used to connect titanium wire and titanium coated copper conductive hook, with a weld strength of ≥ 90% of the substrate;

Surface treatment: Acid washing to remove the oxide layer, anodizing to enhance corrosion resistance.

Corrosion resistance: The corrosion rate of TA2 titanium mesh basket in 60% nitric acid is less than 0.001mm/a;

Conductivity optimization: Titanium coated copper hook design, with a 50% increase in conductivity efficiency compared to pure titanium;

High temperature stability: melting point>1600 ℃, can be used for a long time in an environment of 600 ℃;

Biocompatibility: Compliant with ISO 10993 standard, non-toxic when implanted in the human body;

Lightweight: Density of 4.54g/cm ³, reducing weight by 40% compared to traditional stainless steel mesh baskets.

Electroplating industry: loading copper and nickel anodes, electrolytic metal deposition;

Chemical filtration: media filtration in reaction vessels, seawater desalination filter screens;

Sanitary implantation: orthopedic bone defect repair, dental implant support;

Energy equipment: bipolar plates for hydrogen fuel cells, anode components for electrolytic cells.
